Product Description
A dump semi-trailer, also known as a tipper trailer or dump trailer, is a type of trailer designed for transporting bulk materials and unloading them by tilting the trailer bed. These trailers are commonly used in construction, agriculture, mining, and other industries to transport materials such as sand, gravel, coal, and agricultural produce.
The dump semi-trailer features a hydraulic lifting mechanism that allows the trailer bed to be raised at an angle to dump the cargo. This design enables quick and efficient unloading of materials at the desired location without the need for additional equipment.
Dump semi-trailers come in various sizes and configurations to suit different transportation needs. They are typically pulled by heavy-duty trucks and are essential for transporting loose materials in bulk quantities over short to medium distances. The versatility and efficiency of dump semi-trailers make them valuable assets in many industries where the transportation of bulk materials is required.
Model | Dump Semi Trailer |
Dimension | 10000 x 2500 x 3930mm(Outside); 9000 x 2300 x 1700mm(Inside) |
Curb Weight | 15Tons |
Loading Capacity | 60 Tons (35CBM) |
Cargo Body | Bottom 10mm, side 8mm |
Lifting System | Full set of HYVA hydraulic lifting cylinder |
Kingpin | JOST 2.0 / 3.5 Inch |
Landing Gear | JOST 28 Tons |
Main Beam | Height 500mm, Top flange 14mm, Web 8mm, Bottom flange 16mm |
Side Beam | 18mm steel channel |
Suspension | America type mechanical suspension |
Spring Leaf | 90mm x 13mm x 10 layers |
Axles | FUWA Brand, 13Tons or 16Tons |
Tires | 12.00R20 or 315/80R22.5 |
Brake Chamber | T30/30 + T30 spring brake chamber, one piece of 45L air tanks |
Electrical | 24V |
Tool Box | 1000 x 500 x 500 mm |
